StarTech.com 2-port KVM Console Adapter – Laptop-to-Server – Rackmount Crash Cart Adapter

Manufacturer:StarTech.com
Manufacturer Part Number:SV231USBLC
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:2-Port KVM Console Adapter – Rackmount Crash Cart Adapter
Marketing Information:

This 2-port USB crash-cart adapter gives you KVM control of your servers, directly from your laptop. It’s a convenient solution for routine diagnostics, maintenance and updates for small-scale server applications, giving you full console access to servers located in small spaces, or congested server racks. It’s also perfect for environments where a fixed-installation console server isn’t feasible, such as in a server closet or wall-mounted server rack.

Maximize your IT budget, minimize your hassle

The USB crash-cart adapter offers a cost-effective and convenient way to access and control your servers. At a fraction of the cost of a rack-mounted LCD console, installing this easy-to-use adapter means not having to wheel around a conventional server-room crash cart.

Instead of the expense of a dedicated rack console, or hassle of a full-scale crash cart, you can multi-purpose your laptop and save your IT budget by using equipment you already have on hand.

Streamline your server maintenance

Using the included software, the adapter can do things that regular KVMs can’t. The software provides a robust and flexible interface that lets you view your servers on your full laptop screen, without scroll bars, and lets you reduce the viewing window so that you can work on your laptop and servers at the same time to maximize your productivity.

The software also supports file transfers between your laptop and the servers, which is perfect for server software updates and patches. The adapter’s software also offers video capture support, so you can record your activity on the servers as video, which you can later use for verification or instructional purposes.

Get up and running in minutes

The USB crash cart is easy to install, using the included mounting brackets and 2-in-1 USB and VGA cables. Installing the included software on your laptop is also easy, using the included pre-loaded USB key.

The SV231USBLC is backed by a 2-year StarTech.com warranty, and free lifetime technical support.

Packaged Quantity:1
Product Type:KVM Console

Connectivity Technology:Wired
Number of Computers Supported:2
Number of Local Users Supported:1

Graphic Mode:WUXGA
Maximum Video Resolution:1920 x 1200

USB:Yes
VGA:Yes
Number of VGA Ports:3
Number of USB Ports:8

Input Voltage:

• 120 V AC
• 240 V AC

Input Voltage Range:100V AC to 240V AC
Power Consumption:15 W

Product Color:Black
Form Factor:Rack-mountable
Receiver Height:1″
Receiver Width:3.90″
Receiver Depth:7.70″
Receiver Weight (Approximate):12.87 oz

Package Contents:

• 2-Port KVM Console Adapter – Rackmount Crash Cart Adapter
• 2 x Mounting Brackets
• 2 x 2-in-1 USB and VGA cables – 6 ft
• 1 x USB A to Mini-B cable
• 1 x USB Software Key
• 1 x Universal Power Adapter (NA/EU/UK/AU)
• 1 x Quick Install Guide

Additional Information:

OS Compatibility:

• Windows® XP, Vista, 7, 8, 8.1, 10,11
• Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019, 2022
• macOS 10.6 to 10.15, 11.0, 12.0, 13.0
• Linux 2.6.x to 4.11 (LTS Versions only)

Certifications & Standards:

• CE
• FCC
• UL

Platform Supported:

• PC
• Mac
• Linux

Environmentally Friendly:Yes
Country of Origin:Canada
TAA Compliant:Yes

Limited Warranty:2 Year
